R-6000 CUSHCRAFT Frequency, meters VERTICAL 6-10-12-15-17-20 WITHOUT RADIAL

 R6000 ANTENNE CUSHCRAFT SANS RADIAUX

R6000 CUSHCRAFT Frequency, meters  VERTICAL 6-10-12-15-17-20
SANS RADIAUX

2:1 bandwidth, KHz 10m  > 1700
2:1 bandwidth, KHz 12m  > 100
2:1 bandwidth, KHz 15m  > 450
2:1 bandwidth, KHz 17m  > 100
2:1 bandwidth, KHz 20  > 300
2:1 bandwidth, KHz 6m  > 1300
Frequency, meters  6,10,12,15,17,20
Gain, dBi  3
Height, ft(m)  19(5.8)
Rad horizontal, deg  360
Mast size range, in.(cm)  1.5-1.75(3.8-4.4)
Power, Watts output  1500
Radiation angle, deg.  16
VSWR minimum  1.2:1 typical
Weight, lb(kg)  12.5(5.6)
Wind Surface Secteur ft (m) sq  1.5 (.14)

R6000 CUSHCRAFT Frequency, meters  VERTICAL 6-10-12-15-17-20 SANS RADIAUX
Frequency, meters  6,10,12,15,17,20
Gain, dBi  3
Height, ft(m)  19(5.8)
Rad horizontal, deg  360
Mast size range, in.(cm)  1.5-1.75(3.8-4.4)
Power, Watts output  1500
Radiation angle, deg.  16
VSWR minimum  1.2:1 typical
Weight, lb(kg)  12.5(5.6)
Wind Surface Secteur ft (m) sq  1.5 (.14)
